TP-Link EAP235-Wall AC1200 Wall Plate Access Point — Compact Dual-Band Wi-Fi & Gigabit Networking



The TP‑Link EAP235‑Wall AC1200 Wall Plate Access Point is a slim, wall-mountable access point designed to deliver reliable dual-band wireless coverage (2.4 GHz at up to 300 Mbps + 5 GHz at up to 867 Mbps) using 802.11ac MU-MIMO technology, ideal for homes, offices, hotels or dorms where clean installation and strong connectivity are needed. It offers four full Gigabit Ethernet ports (1 uplink + 3 downlink), with one downlink port supporting PoE passthrough to power a wired device — useful for connecting wired devices like VoIP phones, printers, or cameras without additional wiring. With support for PoE (802.3af/802.3at), installation is flexible and simple, eliminating the need for added power adapters.

Specifications of TP-Link EAP235-Wall AC1200 Wall Plate Access Point — Compact Dual-Band Wi-Fi & Gigabit Networking

Acess Points
Model EAP235-Wall AC1200
Signal Rate • 5 GHz: Up to 867 Mbps • 2.4 GHz: Up to 300 Mbps
Frequency 2.4 GHz and 5 GHz
Network Standard IEEE 802.11a/b/g/n/ac
Interface • Uplink: 1× 10/100/1000 Mbps Ethernet Port • Downlink: 3× 10/100/1000 Mbps Ethernet Ports (One port supports PoE OUT. The PoE OUT feature requires 802.3at PoE+ input and the maximum output is 13 W.)
Buttons Reset
Antenna 2 Dual-Band Antennas • 2.4 GHz: 2× 4 dBi • 5 GHz: 2× 4 dBi
